ATEO6

View larger

Reference: BOKSE MURI

MODEL: ATEO

MARKA: AUDAC

PERSHKRIMI: BOKSE MURI AUDAC LUXURY DESIGN

2-Way 60W RMS 120W MAX 16 Ω

100V 6.25W 12.5W 25W 50W RMS ME SELEKTOR

COLOR: BLACK

MAP: KLIKONI PER ADRESEN:

Kontakt: 0692088111

Email: [email protected]

Vertical and horizontal mounting (rotatable logo)
1" Dome tweeter
6" Low frequency loudspeaker
100V and low impedance connection possibility
Stunning designed and elegant looking ABS enclosure
Patented CleverMount™ mounting system
Multi-tapping 70V / 100V line transformer
Peak Power handling 240W Program Power handling 120W Continuous power (AES) 60W Nominal impedance 8 Ω Sensitivity 1W/1m 89 dB Sound pressure Max W/1m 106 dB @ 8 Ω 105 dB @ 100V Frequency response ± 3dB 65 Hz - 20 kHz Dispersion Horizontal 1200 Vertical 1200 Connectors 2 x WAGO terminal block connections Drivers 6” MF / LF Woofer 1” Dome tweeter Line Transformer Tappings A 800 Ω 12.5W @ 100V 6.25W @ 70V B 400 Ω 25W @ 100V 12.5W @ 70V C 200 Ω 50W @ 100V 25W @ 70V D 100 Ω Not in use @ 100V 50W @ 70V Ingress Protection rating IP66 Construction ABS Front finish Aluminium grill with hydrophobic cloth Colour Black (RAL9005) White (RAL9003) Dimensions (w x h x d) 193.1 x 347.5 x 215.2 mm Weight 3.820 kg Included accessories
